The Schneider Electric Compact NSX100HB2 circuit breaker is engineered for robust protection in demanding industrial environments. This 4-pole breaker, part of the Compact NSX series, offers a high interrupting capacity of 100 kA at 500 VAC, ensuring safety and operational continuity. It is equipped with a Micrologic 2.2 electronic trip unit, factory-set to 40 A, providing precise overcurrent and short-circuit protection.

Technical details

• Series: Compact NSX
• Model: NSX100HB2
• Number of Poles: 4
• Rated Current: 40 A (via Micrologic 2.2 trip unit)
• Interrupting Capacity: 100 kA at 500 VAC
• Trip Unit: Micrologic 2.2
• Voltage Rating: 500 VAC
• Form Factor: 4d (refer to manufacturer datasheet for detailed dimensions and mounting specifications)

Applications & compatibility

This circuit breaker is suitable for use in power distribution systems, motor control circuits, and as a main or branch circuit protector in various industrial settings. It is commonly found in applications such as manufacturing plants, data centers, and building management systems where reliable and high-capacity circuit protection is essential.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LV433331 or contact our technical team for cross-reference assistance with compatible Compact NSX components.
