The Schneider Electric Compact NSX100HB2 is a 4-pole circuit breaker designed for robust electrical protection in industrial environments. This unit features a 100 kA interrupting rating at 500 VAC, ensuring safety and reliability in high-fault current situations. It incorporates the Micrologic 2.2 electronic trip unit, configured for a 100 A rating, providing advanced overcurrent and short-circuit protection.

Technical details

• Series: Compact NSX
• Model: NSX100HB2
• Number of Poles: 4
• Interrupting Capacity: 100 kA at 500 VAC
• Trip Unit: Micrologic 2.2
• Current Rating: 100 A
• Configuration: 4d (likely refers to auxiliary contacts or specific internal configuration, verify with datasheet)
• Voltage Rating: Up to 500 VAC

Applications & compatibility

This circuit breaker is suitable for use in motor control centers, distribution panels, and power distribution systems within manufacturing plants, data centers, and infrastructure projects. Its high interrupting rating makes it ideal for applications requiring protection against severe short circuits, such as those found in heavy machinery and large industrial complexes.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LV433333 or contact our technical team for cross-reference assistance with compatible Compact NSX components.
