The Schneider Electric Compact NSX100HB2 is a 4-pole circuit breaker designed for robust electrical protection in demanding industrial environments. This unit features a 100 kA interrupting capacity at 500 VAC, ensuring safety and reliability in high-fault current situations. It incorporates the Micrologic 5.2 E trip unit, providing advanced protection and control capabilities.

Technical details

• Series: Compact NSX
• Model: NSX100HB2
• Number of Poles: 4
• Rated Current: 40 A
• Interrupting Capacity: 100 kA at 500 VAC
• Trip Unit: Micrologic 5.2 E
• Voltage Rating: Up to 500 VAC
• Configuration: 4d (likely indicating 4 normally open auxiliary contacts, verify with manufacturer datasheet)

Applications & compatibility

This circuit breaker is suitable for use in motor control centers, power distribution panels, and machinery requiring reliable overcurrent and short-circuit protection. Its high interrupting rating makes it appropriate for applications with significant fault current potential, such as those found in manufacturing plants, data centers, and large commercial buildings.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LV433338 or contact our technical team for cross-reference assistance with compatible Compact NSX components.
