The Schneider Electric Compact NSX100HB2 is a 4-pole circuit breaker designed for robust electrical protection in industrial environments. This unit features a 100 Ampere rating and a high interrupting capacity of 100 kA at 500 VAC, making it suitable for demanding applications where fault current protection is critical. It incorporates the Micrologic 5.2 E trip unit, providing advanced protection and monitoring capabilities.

Technical details

• Series: Compact NSX
• Model: NSX100HB2
• Trip Unit: Micrologic 5.2 E
• Current Rating: 100 A
• Number of Poles: 4
• Interrupting Capacity: 100 kA at 500 VAC
• Configuration: 4d (typically refers to the number of auxiliary contacts or signaling functions, buyer should verify against datasheet)

Applications & compatibility

This circuit breaker is commonly deployed in power distribution systems for manufacturing facilities, data centers, and commercial buildings. It is designed to protect electrical circuits in motor control centers, switchboards, and power distribution panels, ensuring the reliable operation of machinery such as conveyor systems, pumps, and HVAC equipment.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LV433340 or contact our technical team for cross-reference assistance with compatible Compact NSX components.
