The Schneider Electric ComPact NSX100HB2 is a high-performance circuit breaker designed for robust electrical protection in demanding industrial environments. Part of the ComPact NSX series, this unit is engineered to safeguard electrical distribution systems against overcurrents and short circuits. Its construction supports critical applications where reliable power continuity is paramount, such as in manufacturing facilities and large commercial buildings.

Technical details

• Series: ComPact NSX
• Model: NSX100HB2
• Rated Breaking Capacity: 100 kA at 500 VAC
• Trip Unit: Micrologic 6.2 E
• Current Rating: 40 A
• Number of Poles: 4 (4d configuration)
• Voltage Rating: Suitable for systems up to 500 VAC
• Configuration: 4-pole breaker for comprehensive circuit isolation

Applications & compatibility

This circuit breaker is ideal for use in main distribution panels, motor control centers, and sub-distribution boards within industries such as food and beverage processing, automotive manufacturing, and water treatment. It is compatible with various Schneider Electric ComPact NSX system components, ensuring seamless integration into existing electrical infrastructure.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LV433342 or contact our technical team for cross-reference assistance with compatible ComPact NSX components.
