The Schneider Electric Compact NSX100HB2 is a 4-pole circuit breaker designed for robust electrical protection in demanding industrial environments. This unit features a high interrupting capacity of 100 kA at 500 VAC, ensuring safety and reliability in fault conditions. It integrates the advanced Micrologic 6.2 E trip unit, offering precise current sensing and protection settings.

Technical details

• Series: Compact NSX
• Model: NSX100HB2
• Configuration: 4-pole (4d)
• Interrupting Capacity: 100 kA at 500 VAC
• Trip Unit: Micrologic 6.2 E
• Rated Current: 100 A
• Voltage Rating: Up to 500 VAC
• Protection Functions: Long-time, short-time, instantaneous, and ground fault protection (as determined by Micrologic 6.2 E capabilities)

Applications & compatibility

This circuit breaker is suitable for use in power distribution systems, motor control centers, and main switchboards across various industries. It provides essential protection for electrical circuits in applications such as manufacturing plants, data centers, and commercial buildings, ensuring the integrity of power supply to critical equipment.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LV433344 or contact our technical team for cross-reference assistance with compatible Compact NSX components.
