The Schneider Electric Compact NSX80 DC PV circuit breaker is engineered for photovoltaic (PV) power systems. This 4-pole breaker is rated for 80 Amperes and features a 1000 VDC interrupting capacity, making it suitable for high-voltage DC applications. It incorporates a TM-D trip unit for reliable overcurrent protection.

Technical details

• Series: Compact NSX DC PV
• Type: DC Circuit Breaker
• Poles: 4
• Current Rating: 80 A
• Voltage Rating: 1000 VDC
• Trip Unit: TM-D
• Application: Designed for photovoltaic (PV) DC power distribution and protection
• Interrupting Capacity: 1000 VDC

Applications & compatibility

This Schneider Electric circuit breaker is specifically designed for use in solar power installations, including utility-scale solar farms, commercial rooftop PV systems, and off-grid DC power solutions. It provides essential protection for DC strings and combiners, ensuring the safety and reliability of photovoltaic energy generation equipment.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LV438081 or contact our technical team for cross-reference assistance with compatible Compact NSX DC PV components.
