The Schneider Electric Compact NSX100NA DC PV is a 4-pole switch disconnector designed for photovoltaic (PV) applications. This unit provides reliable circuit isolation and protection within DC power systems, commonly integrated into solar power generation infrastructure.

Technical details

• Series: Compact NSX
• Type: Switch Disconnector
• Poles: 4
• Current Rating: 100 A
• Application: DC PV (Photovoltaic)
• Voltage Class: Specific DC voltage rating should be verified against manufacturer datasheet.
• Interrupting Capacity: Specific DC interrupting capacity should be verified against manufacturer datasheet.
• Terminal Type: Screw terminals (typical for this series, verify against datasheet)

Applications & compatibility

This switch disconnector is engineered for use in solar power plants, rooftop solar installations, and other DC power distribution systems where safe isolation of PV arrays is required. It is compatible with various DC combiner boxes and inverters commonly found in renewable energy systems.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LV438100 or contact our technical team for cross-reference assistance with compatible Compact NSX components.
