The Schneider Electric Compact NSX160NA DC PV is a 4-pole switch disconnector designed for DC photovoltaic applications. This unit provides reliable isolation and protection for solar power systems, ensuring safe maintenance and operation. Its robust construction is engineered to meet the demanding requirements of renewable energy installations.

Technical details

• Series: Compact NSX
• Type: Switch Disconnector
• Application: DC Photovoltaic (PV)
• Number of Poles: 4
• Rated Current: 160 A
• Voltage Rating: Verify against manufacturer datasheet for specific DC voltage class (e.g., 1000V DC).
• Interrupting Capacity: Verify against manufacturer datasheet for specific DC breaking capacity.
• Terminal Type: Verify against manufacturer datasheet for specific terminal configuration.

Applications & compatibility

This switch disconnector is specifically designed for use in DC combiner boxes and inverters within solar power plants. It ensures safe and compliant isolation of solar arrays, making it suitable for utility-scale solar farms, commercial rooftop installations, and off-grid solar systems.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LV438160 or contact our technical team for cross-reference assistance with compatible Compact NSX components.
