The Schneider Electric Compact NSX1000 DC circuit breaker is a 2-pole (2P) device designed for DC power distribution and protection. As part of the NSX series, this breaker is engineered for robust performance in demanding industrial environments, commonly found in DC power systems for renewable energy installations, industrial machinery, and specialized DC motor control applications.

Technical details

• Series: Compact NSX DC
• Type: DC Circuit Breaker
• Poles: 2-Pole (2P)
• Current Rating: 1000 A
• Trip Unit Type: TM-DC (Thermal-Magnetic DC)
• Voltage Class: DC (Specific voltage rating requires datasheet verification)
• Interrupting Capacity: Requires datasheet verification
• Mounting Type: Requires datasheet verification

Applications & compatibility

This 1000A DC circuit breaker is suitable for applications requiring reliable protection of DC circuits, including solar inverters, battery storage systems, DC traction drives, and industrial DC power distribution panels. Its TM-DC trip unit provides thermal overload and magnetic short-circuit protection, essential for safeguarding sensitive DC equipment.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LV438363 or contact our technical team for cross-reference assistance with compatible Compact NSX DC components.
