The Schneider Electric Compact NSX630 TM-DC is a two-pole circuit breaker designed for DC power distribution and protection. This unit is part of the NSX series, known for its robust construction and reliable performance in demanding industrial environments. It offers a significant interrupting capacity, making it suitable for applications requiring protection against high fault currents.

Technical details

• Series: Compact NSX
• Model Designation: TM-DC
• Number of Poles: 2
• Rated Current: 630 A
• Interrupting Capacity: 50 kA at 600 VDC
• Configuration: Without bare cable connector
• Voltage Rating: 600 VDC

Applications & compatibility

This circuit breaker is engineered for use in DC power systems within industries such as renewable energy (solar farms), electric vehicle charging infrastructure, and industrial DC motor control applications. Its high interrupting rating ensures safety and operational continuity in systems where significant fault currents are a concern.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LV438545 or contact our technical team for cross-reference assistance with compatible Compact NSX components.
