The Schneider Electric Compact NSX_800 TM-DC circuit breaker is engineered for robust DC power distribution and protection. This 2-pole breaker is a critical component for systems requiring reliable interruption of fault currents up to 50 kA at 600 VDC. Its design is optimized for demanding industrial environments where precise and dependable circuit protection is paramount.

Technical details

• Series: Compact NSX
• Model Designation: TM-DC
• Number of Poles: 2
• Rated Current: 800 A
• Interrupting Capacity: 50 kA at 600 VDC
• Configuration: Without bare cable connector
• Voltage Rating: 600 VDC
• Type: DC Circuit Breaker

Applications & compatibility

This Schneider Electric circuit breaker is commonly deployed in DC power distribution systems for heavy industrial machinery, renewable energy installations, and specialized DC motor control applications. It is suitable for use in environments such as material handling, electric vehicle charging infrastructure, and industrial process control where high DC fault currents must be safely managed.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LV438546 or contact our technical team for cross-reference assistance with compatible Compact NSX components.
