The Schneider Electric Compact NSX100N is a 1-pole circuit breaker designed for AC and DC applications. This unit features a 20 Amp TMD trip unit and offers a breaking capacity of 25 kA at 240 VAC. It is a component commonly integrated into power distribution systems and motor control circuits within industrial environments.

Technical details

• Series: Compact NSX
• Model: NSX100N
• Poles: 1
• Trip Unit Type: TMD
• Trip Unit Rating: 20 A
• AC Breaking Capacity: 25 kA at 240 VAC
• DC Capability: Yes (AC/DC rated)
• Configuration: 1d (likely refers to a specific internal contact configuration or accessory slot, buyer should verify against datasheet)

Applications & compatibility

This circuit breaker is suitable for use in a variety of industrial settings, including control panels, power distribution units, and motor protection circuits. It is designed to protect electrical equipment from overcurrents and short circuits in applications such as conveyor systems, pump controls, and HVAC systems.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LV438573 or contact our technical team for cross-reference assistance with compatible Compact NSX components.
