The Schneider Electric EasyPact CVS100F circuit breaker is designed for robust electrical protection in industrial environments. This 4-pole (4P) molded case circuit breaker features a thermal magnetic trip unit, specifically the TM-D type, offering reliable overcurrent and short-circuit protection. Its 3d designation indicates three distinct trip functions.

Technical details

• Series: EasyPact CVS
• Model: CVS100F
• Number of Poles: 4P
• Rated Current: 40 A
• Trip Unit Type: Thermal Magnetic (TM-D)
• Interrupting Capacity: 36 kA at 415 VAC
• Trip Functions: 3d (indicating three distinct trip functions)
• Voltage Rating: Suitable for systems up to 415 VAC

Applications & compatibility

This circuit breaker is commonly employed in power distribution systems for commercial and light industrial applications. It provides essential protection for electrical panels, motor control centers, and branch circuits in facilities such as manufacturing plants, warehouses, and commercial buildings.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LV510343 or contact our technical team for cross-reference assistance with compatible EasyPact components.
