The Schneider Electric LX1FH0242 is a TeSys F series contactor coil designed for AC control circuits. This coil operates at a nominal voltage of 24V AC and is compatible with frequencies ranging from 40 to 400 Hz. It is a critical component for the reliable operation of TeSys F contactors, enabling them to switch power circuits in various industrial applications.

Technical details

• Series: TeSys F
• Coil Voltage: 24V AC
• Frequency Range: 40 - 400 Hz
• Type: Contactor Coil
• Function: Controls the electromagnetic operation of TeSys F contactors
• Compatibility: Designed for use with Schneider Electric TeSys F contactors
• Insulation Class: Refer to manufacturer datasheet for specific insulation ratings
• Operating Temperature Range: Refer to manufacturer datasheet for specific operating temperature limits

Applications & compatibility

This LX1FH0242 coil is integral to the functioning of TeSys F contactors, commonly found in motor control applications within manufacturing facilities. It is suitable for use in systems requiring precise and reliable switching of electrical loads, such as on assembly lines, in material handling equipment, and within HVAC control systems.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LX1FH0242 or contact our technical team for cross-reference assistance with compatible TeSys F components.
