The Schneider Electric TeSys F contactor coil, model LX1FH1102, is designed for AC control circuits operating within a specific voltage and frequency range. This coil is a key component for activating TeSys F series contactors, enabling the switching of high-power electrical loads in industrial automation systems. Its construction is engineered for reliable operation in demanding environments.

Technical details

• Series: TeSys F
• Coil Type: Contactor Coil
• Voltage Rating: 110...115 V AC
• Frequency Rating: 40...400 Hz
• Control Circuit Function: Enables contactor operation
• Compatibility: Designed for use with Schneider Electric TeSys F series contactors. Specific contactor models should be verified against manufacturer documentation.
• Operating Temperature Range: Consult manufacturer datasheet for precise specifications.
• Mounting Type: Typically plug-in or screw terminal, depending on the associated contactor.

Applications & compatibility

This LX1FH1102 coil is integral to the operation of TeSys F contactors, commonly found in motor control applications, power distribution panels, and control systems for machinery in sectors such as manufacturing, material handling, and HVAC. It ensures precise and responsive switching for a wide array of industrial equipment.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LX1FH1102 or contact our technical team for cross-reference assistance with compatible TeSys F components.
