The Schneider Electric LX1FH2402 is a TeSys F series contactor coil designed for AC control circuits. This coil operates at a nominal voltage of 240V AC and is engineered to function within a frequency range of 40 to 400 Hz, making it suitable for a variety of industrial power systems. It serves as a critical component in the actuation mechanism of TeSys F contactors, enabling the switching of electrical loads.

Technical details

• Series: TeSys F
• Coil Voltage: 240V AC
• Frequency Range: 40-400 Hz
• Type: Contactor Coil
• Control Circuit Component: Yes
• Actuation Method: Electromagnetic
• Compatible Contactor Series: TeSys F
• Insulation Class: Verify with manufacturer datasheet for specific rating.

Applications & compatibility

This LX1FH2402 coil is integral to the operation of TeSys F contactors used in motor control applications, power distribution, and automation systems. It is commonly found in heavy-duty industrial environments such as manufacturing plants, material handling equipment, and large machinery where reliable and robust electrical switching is paramount.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LX1FH2402 or contact our technical team for cross-reference assistance with compatible TeSys F components.
