The Schneider Electric LX1FH3802 is a TeSys F series contactor coil designed for AC control circuits. This coil operates within a voltage range of 380 to 415 Volts AC and supports frequencies from 40 to 400 Hz, making it suitable for a variety of industrial power systems. It is engineered to provide reliable switching operations for TeSys F contactors, a robust line of motor control components.

Technical details

• Series: TeSys F
• Product Type: Contactor Coil
• Control Voltage: 380...415 V AC
• Frequency Range: 40...400 Hz
• Coil Type: LX1FH
• Application: Designed for use with Schneider Electric TeSys F contactors to enable coil energization and de-energization for motor control applications.
• Mounting: Typically designed for plug-in installation into compatible TeSys F contactor bodies.
• Environmental Rating: Refer to the manufacturer's datasheet for specific environmental protection ratings.

Applications & compatibility

This LX1FH3802 contactor coil is commonly integrated into motor control centers and electrical panels for heavy-duty industrial applications. It is essential for controlling large motors in sectors such as material handling, HVAC systems, and process automation where reliable and frequent switching is required.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LX1FH3802 or contact our technical team for cross-reference assistance with compatible TeSys F components.
