The Schneider Electric OSMC65H1D2 is a miniature circuit breaker designed for single-phase electrical protection. This device operates at a nominal voltage of 240V and a frequency of 50Hz, providing reliable overcurrent and short-circuit protection for various industrial applications. Its D2A trip curve characteristic indicates a specific response time to fault currents, making it suitable for protecting sensitive equipment.

Technical details

• Series: OSMC
• Voltage Rating: 240V AC
• Frequency: 50Hz
• Number of Poles: 1P (Single Pole)
• Trip Curve: D2A
• Interrupting Capacity: Not specified; refer to manufacturer datasheet for details.
• Terminal Type: Not specified; refer to manufacturer datasheet for details.
• Mounting Type: DIN Rail Mount (typical for miniature circuit breakers)

Applications & compatibility

This miniature circuit breaker is commonly employed in control panels, distribution boards, and machinery requiring precise single-phase circuit protection. It is suitable for use in environments such as manufacturing facilities, automation systems, and building services where reliable electrical safety is paramount. Compatibility with 240V, 50Hz systems is essential.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the OSMC65H1D2 or contact our technical team for cross-reference assistance with compatible Schneider Electric protection components.
