The Schneider Electric Square D 8536SEO1V02H20S is a NEMA Size 3 non-reversing starter designed for full-voltage starting and stopping of AC squirrel cage motors. This starter is part of the 8536 series and is engineered for reliable motor control in demanding industrial environments. It provides robust protection and operational control for motors up to 30 HP.

Technical details

• Series: Square D 8536
• NEMA Size: 3
• Configuration: Non-reversing
• Voltage Rating: 600VAC
• Amperage Rating: 90 Amps
• Horsepower Rating: 25 HP at 200 VAC, 30 HP at 230 VAC. For higher voltage ratings, consult the manufacturer's datasheet.
• Enclosure Type: Open style (as indicated by the base part number structure, verify specific enclosure needs against manufacturer documentation).
• Control Voltage: The 'H20' in the part number typically indicates a 120VAC control voltage coil. Verify this specification against the manufacturer's datasheet for your specific application.

Applications & compatibility

This starter is commonly employed in applications requiring direct on-line motor starting and stopping, such as pump controls, fan systems, and conveyor belt drives. It is suitable for use in general industrial machinery, manufacturing plants, and processing facilities where reliable motor management is critical.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the Schneider Electric Square D 8536SEO1V02H20S or contact our technical team for cross-reference assistance with compatible Square D components.
