The Schneider Electric Square D EX150T1814H is a 150 kVA, 3-phase dry-type transformer engineered for low-voltage electrical distribution. This unit is designed to meet the energy efficiency requirements of DOE 2016 standards, making it suitable for commercial and industrial facilities requiring reliable power conversion.

Technical details

• Transformer Type: Dry-Type
• Apparent Power Rating: 150 kVA
• Phase: 3-Phase
• Primary Voltage: 480V Delta
• Secondary Voltage: 480Y/277V
• Frequency: 60 Hz (standard for this voltage configuration)
• Enclosure Type: Ventilated (typical for dry-type transformers of this rating)
• Insulation Class: 220°C (typical for this voltage and kVA rating)

Applications & compatibility

This transformer is commonly deployed in commercial buildings, manufacturing plants, and data centers to step down utility power for local distribution. It is compatible with standard 480V delta primary power sources and provides a stable 480Y/277V secondary for a wide range of equipment, including lighting systems and machinery.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the Schneider Electric Square D EX150T1814H or contact our technical team for cross-reference assistance with compatible transformer components.
