The Schneider Electric Square D KHL36000MV is an automatic molded case switch designed for robust circuit protection in industrial environments. This specific model operates at 600V AC and is rated for 250 Amperes, making it suitable for medium to high voltage distribution systems. Its construction within the KHL series indicates a focus on reliability and safety for critical power management.

Technical details

• Series: Square D KHL
• Voltage Rating: 600V AC
• Amperage Rating: 250A
• Type: Automatic Molded Case Switch
• Frame Size: Determined by KHL36000MV part number encoding; consult manufacturer datasheet for precise dimensions and internal trip unit specifications.
• Interrupting Capacity: Consult manufacturer datasheet for specific AIC rating.
• Terminal Type: Consult manufacturer datasheet for terminal configuration and size.
• Operating Mechanism: Consult manufacturer datasheet for details on manual and automatic trip functions.

Applications & compatibility

This Schneider Electric Square D molded case switch is commonly employed in main distribution panels, motor control centers, and as a protective device for large electrical loads. Its 600V rating makes it suitable for applications found in manufacturing plants, heavy industry, and commercial facilities requiring reliable overcurrent and short-circuit protection.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the Schneider Electric Square D KHL36000MV or contact our technical team for cross-reference assistance with compatible KHL series components.
