Schneider Electric's TeSys D series LC1D1150046MD is a 4-pole contactor designed for robust motor control and power switching applications. This specific model features four normally open (4NO) contacts, making it suitable for circuits requiring reliable make-before-break or break-before-make operations in control systems. It is engineered to handle demanding industrial environments and ensure consistent performance in electrical distribution and motor starter assemblies.

Technical details

• Series: TeSys D
• Model Number: LC1D1150046MD
• Number of Poles: 4
• Contact Configuration: 4 Normally Open (4NO)
• AC-1 Utilization Category: Rated for AC-1 operation up to 440 Volts.
• AC-1 Current Rating: Capable of handling 200 Amps at 50 Hz for AC-1 loads.
• Coil Voltage: The '004' in the part number typically indicates a 24V DC coil voltage. Please verify with the manufacturer's datasheet for confirmation.
• Mounting Type: Designed for panel mounting.

Applications & compatibility

The Schneider LC1D1150046MD is commonly employed in industrial control panels for starting and stopping three-phase motors, particularly in applications such as HVAC systems, pump controls, and conveyor systems. Its 4NO configuration makes it ideal for specific control logic where multiple circuits need to be simultaneously closed upon activation, such as in bypass arrangements or multi-motor sequencing.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the LC1D1150046MD or contact our technical team for cross-reference assistance with compatible TeSys D components.
