The Schneider Electric LV429764 is a Compact NSX100H circuit breaker, engineered for robust protection in electrical distribution systems. This unit is specifically designed for motor protection applications, offering a compact footprint without compromising on breaking capacity. Its construction ensures reliable operation in demanding industrial environments.

Technical Details

• Series: Compact NSX100H
• Rated Service Breaking Capacity (Ics): 70 kA at 415 VAC
• Rated Ultimate Breaking Capacity (Icu): 70 kA at 415 VAC
• Rated Service Breaking Capacity (Ics): 10 kA at 600 VAC
• Rated Ultimate Breaking Capacity (Icu): 10 kA at 600 VAC
• Frame Size: 100 A
• Trip Unit Type: Thermal-magnetic (indicated by 'H' in the part number, typically denotes a higher breaking capacity variant)
• Number of Poles: 3
• Connection Type: Screw terminals

Applications & Compatibility

This circuit breaker is commonly deployed in motor control centers (MCCs), power distribution panels, and machinery requiring precise motor overload and short-circuit protection. It is suitable for use in industries such as manufacturing, food and beverage processing, and water treatment where reliable power management is critical for operational continuity.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the Schneider Electric LV429764 or contact our technical team for cross-reference assistance with compatible Compact NSX components.
