Designed for standard distribution applications, the Schneider Electric Compact NSX100HB2 circuit breaker optimizes space and breaking capacity. This three-pole, 3D fixed device delivers robust performance and reliability in demanding electrical environments. Its construction ensures efficient power management and protection for electrical circuits.

Technical details

• Series: Compact NSX
• Model Designation: NSX100HB2
• Number of Poles: 3
• Mounting Type: Fixed
• Breaking Capacity: 100 kA at 500 VAC
• Configuration: 3D (three-pole, double-break contact system)
• Current Rating: 100 A (derived from NSX100 designation)
• Voltage Rating: 500 VAC (derived from breaking capacity specification)

Applications & compatibility

This circuit breaker is suitable for use in industrial power distribution panels, motor control centers, and electrical switchgear. It provides essential overcurrent protection for a variety of machinery and systems, including manufacturing equipment, process control systems, and building electrical infrastructure.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the Schneider Electric LV433226 or contact our technical team for cross-reference assistance with compatible Compact NSX components.
