This Schneider Electric TM7 expansion bus cable connects automation devices within a system, facilitating communication over a dedicated bus. Designed for robust industrial environments, the TCSXCN1FNX25E utilizes M12 connectors for secure and reliable data transfer. This cable is integral to expanding the reach and functionality of TM7 I/O modules in distributed control architectures.

Technical details

• Series: TM7 Expansion Bus
• Connector Type (Female End): M12, 4-pin, B-coded
• Cable Length: 25 meters
• Cable Configuration: Straight connection
• Protocol Support: TM7 Expansion Bus protocol
• Environmental Rating: Suitable for industrial environments (verify specific IP rating against manufacturer datasheet)
• Wire Termination: Female wire termination on one end for connection to expansion modules
• System Compatibility: Designed for use with Schneider Electric Modicon M340, M580, and other compatible PLC systems utilizing the TM7 expansion bus.

Applications & compatibility

The Schneider Electric TCSXCN1FNX25E is commonly deployed in applications requiring distributed I/O and extended communication distances. This includes integration into packaging machinery, material handling systems, process control loops, and building automation networks where reliable expansion bus connectivity is paramount.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the TCSXCN1FNX25E or contact our technical team for cross-reference assistance with compatible TM7 expansion bus components.
