The Schneider Electric TM5CAI8O8CL is a compact I/O expansion block designed for modular automation systems. As part of the Modicon TM5 series, this module provides 8 analog inputs and 8 analog outputs, specifically configured for 4-20 mA current loop signals. Its 12-bit resolution ensures precise signal conversion for demanding control applications.

Technical details

• Series: Modicon TM5
• Module Type: Compact I/O Expansion Block
• Analog Inputs: 8 channels
• Analog Outputs: 8 channels
• Signal Type: 4-20 mA current loop
• Resolution: 12 bits
• Form Factor: Compact, designed for DIN rail mounting within TM5 system racks
• Communication Protocol: Compatible with TM5 bus communication (specific protocol details should be verified against manufacturer datasheet)

Applications & compatibility

This TM5CAI8O8CL expansion module is suitable for integration into various industrial automation architectures, including process control, machine building, and SCADA systems. It is commonly found in applications requiring precise monitoring and control of analog signals, such as temperature, pressure, flow, and level instrumentation on packaging lines, chemical processing equipment, or material handling systems.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the TM5CAI8O8CL or contact our technical team for cross-reference assistance with compatible Modicon TM5 system components.
