The Schneider Electric TM5SAI4AFS is an analog input module designed for Modicon M580 ePAC systems. This module features a Form Factor S (FS) and supports 2 analog inputs, specifically configured for 4-20 mA current signals. With a resolution of 24 bits, it provides precise measurement capabilities for process control applications.

Technical details

• Series: Modicon M580
• Module Type: Analog Input Module
• Form Factor: FS (Form Factor S)
• Number of Analog Inputs: 2
• Input Signal Type: 4-20 mA current
• Resolution: 24 bits
• Power Supply: Requires 24 VDC (verify specific voltage requirements with manufacturer datasheet)
• Communication Protocol: Compatible with Modicon M580 backplane communication

Applications & compatibility

This analog input module is integral to process automation within industries requiring precise signal acquisition. It is commonly deployed in applications such as chemical processing, water treatment facilities, food and beverage production lines, and environmental monitoring systems where accurate measurement of process variables like pressure, flow, or level is critical.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the TM5SAI4AFS or contact our technical team for cross-reference assistance with compatible Modicon M580 components.
