The Schneider Electric TSXAEZ801 is an analog input module designed for the TSX Micro series of programmable logic controllers. This module provides eight channels for analog signal acquisition, specifically configured for 0-10 VDC input signals. It is commonly integrated into automation systems requiring precise monitoring of analog sensor data.

Technical details

• Series: TSX Micro
• Module Type: Analog Input Module
• Number of Channels: 8
• Input Signal Type: 0-10 VDC
• Voltage Range: 0 to 10 Volts Direct Current
• Compatibility: Designed for use with Schneider Electric TSX Micro PLCs. Specific PLC processor compatibility should be verified against the manufacturer's datasheet.
• Form Factor: Module designed for DIN rail mounting within a TSX Micro rack system.
• Protocol: Internal communication protocol specific to the TSX Micro backplane.

Applications & compatibility

This analog input module is suitable for applications demanding precise measurement of voltage-based analog signals. It finds use in process control, machine monitoring, and data acquisition systems within industries such as food and beverage processing, water treatment, and general manufacturing. Ensure compatibility with your specific TSX Micro PLC processor and rack configuration by consulting the manufacturer's documentation.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the TSXAEZ801 or contact our technical team for cross-reference assistance with compatible TSX Micro components.
