The Schneider Electric TWDDRA16RT serves as an expansion unit for automation systems, providing 16 relay outputs. This module is designed for integration into control architectures requiring additional output points for switching external devices. Its configuration suggests use in applications where discrete control signals are necessary to manage machinery or process equipment.

Technical details

• Series: TWDDRA
• Output Type: Relay
• Number of Outputs: 16
• Coil Voltage: 24 VDC
• Output Current Rating: 75 mA per output
• Form Factor: Expansion Module
• Functionality: Provides 16 independent relay outputs for switching AC or DC loads.
• Compatibility: Designed for use with compatible Schneider Electric control platforms. Verify specific controller compatibility with the manufacturer's datasheet.

Applications & compatibility

This expansion unit is suitable for extending the I/O capabilities of programmable logic controllers (PLCs) in various industrial settings. Common applications include packaging machinery, material handling systems, and process control loops where additional switching functions are required. Its 24 VDC coil voltage makes it compatible with standard DC control power supplies found in most automation environments.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the TWDDRA16RT or contact our technical team for cross-reference assistance with compatible Schneider Electric expansion modules.
