The Schneider Electric VW3A3601 is an EtherCAT communication module designed to extend the connectivity options for compatible Schneider Electric drives and automation systems. This module facilitates high-speed, deterministic communication over an EtherCAT network, enabling advanced control and synchronization in complex industrial environments. It is a key component for integrating variable speed drives into modern, networked automation architectures.

Technical details

• Communication Protocol: EtherCAT
• Physical Interface: 2 x RJ45 connectors
• Module Type: Communication Option Module
• Manufacturer Series: Altivar Process (VW3A36xx series)
• Data Transfer Rate: Up to 100 Mbps (Ethernet standard)
• Network Topology: Supports line, star, and ring topologies
• Diagnostic Capabilities: Provides network status and error reporting
• Power Consumption: Typically low, refer to manufacturer datasheet for exact figures

Applications & compatibility

This EtherCAT module is commonly integrated into industrial automation systems requiring precise motion control and high-speed data exchange. It is particularly suited for applications such as packaging machinery, robotics, CNC machines, and automated assembly lines where synchronized multi-axis control is essential. The VW3A3601 ensures seamless integration with compatible Schneider Electric Altivar Process drives.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the VW3A3601 or contact our technical team for cross-reference assistance with compatible Altivar Process components.
