This Schneider Electric VW3M7102R150 is a DC bus connection component designed for daisy-chaining within specific drive systems. It facilitates power distribution without requiring a separate connector, streamlining installation in compatible automation setups. This component is integral to building modular and expandable drive architectures.

Technical details

• Series/Family: Likely part of the Schneider Electric Altivar variable speed drive accessories or a related power distribution system.
• Connection Type: Daisy Chain DC Bus connection.
• Connector Requirement: No external connector required for DC bus connection.
• Functionality: Enables direct power linking between drive modules or power blocks.
• Voltage/Current Rating: Specific voltage and current ratings are not explicitly defined by the provided part number and require verification against the manufacturer's datasheet for the intended system.
• Form Factor: Designed for integration within a specific enclosure or mounting system, details of which should be confirmed via manufacturer documentation.
• Protocol Compatibility: While not a communication module, its integration is dependent on the DC bus protocol of the associated Schneider Electric drive system.

Applications & compatibility

The VW3M7102R150 is commonly utilized in industrial automation environments requiring robust and scalable motor control solutions. It is typically found in applications such as packaging machinery, material handling systems, and process control where multiple drives are networked together for synchronized operation or shared DC bus configurations.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the VW3M7102R150 or contact our technical team for cross-reference assistance with compatible Schneider Electric drive system components.
