The Schneider Electric VX4DCPD45N4 is a DC bus board designed for SCR-IGBT power conversion systems. This component is integral to motor control applications requiring robust power handling and precise DC bus management. It facilitates the connection and distribution of DC power within a 400V system, supporting up to 45kW of power.

Technical details

• Series: VX4D
• Voltage Class: 400V DC Bus
• Power Rating: 45kW
• Component Type: DC Bus Board
• Technology Support: SCR-IGBT
• Form Factor: Board-level component for integration into larger power cabinets.
• Functionality: Distributes and manages the DC bus voltage for power conversion stages.
• For detailed specifications and compatibility, please consult the manufacturer's datasheet.

Applications & compatibility

This DC bus board is commonly employed in industrial drives and power conversion systems where high power SCR-IGBT technology is utilized. Applications include variable speed drives for heavy machinery, industrial process control, and power generation systems. Its design ensures reliable DC bus performance in demanding environments.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the VX4DCPD45N4 or contact our technical team for cross-reference assistance with compatible Schneider Electric power components.
