The Schneider Electric VX5A1202F is a Gate Drive PCB designed for IGBT modules in Size 1 configurations. This component is integral to the control and switching of power transistors within variable speed drives and motor control systems. It facilitates the precise application of gate voltage required to switch high-power Insulated Gate Bipolar Transistors (IGBTs) efficiently and reliably.

Technical details

• Product Type: Gate Drive Printed Circuit Board (PCB)
• Manufacturer Series: VX5A
• IGBT Module Size Compatibility: Size 1
• Functionality: Provides the necessary voltage and current signals to control the gate of IGBT power modules.
• Application Focus: Designed for integration within power electronic systems requiring precise IGBT switching.
• Component Type: Control board for power semiconductor switching.
• Voltage Class: Specific voltage class should be verified against the manufacturer's datasheet for the complete drive system.
• Current Rating: Specific current rating should be verified against the manufacturer's datasheet for the complete drive system.

Applications & compatibility

This VX5A1202F Gate Drive PCB is commonly found in industrial automation systems that utilize IGBT modules for motor control and power conversion. Applications include variable frequency drives (VFDs), servo drives, and other power electronic converters used in manufacturing, material handling, and process control equipment.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the VX5A1202F or contact our technical team for cross-reference assistance with compatible Schneider Electric drive components.
