The Schneider Electric VZ3IM1600M1271 is a high-power IGBT module designed for demanding industrial applications. As part of the TD Series, this power block utilizes hybrid SCR-diode technology to deliver robust performance in power conversion and control systems. Its construction is optimized for efficient heat dissipation and reliable operation under heavy loads.

Technical details

• Series: TD Series
• Module Type: IGBT Module / Power Block
• Technology: Hybrid SCR-Diode
• Current Rating: 285 Amps
• Voltage Rating: 1600 Volts
• Configuration: Power Module
• Terminal Type: M1271 (refer to datasheet for specific terminal configuration)

Applications & compatibility

This IGBT module is suitable for use in variable speed drives, inverters, and power converters commonly found in heavy industry. Applications include motor control for pumps, fans, and conveyors, as well as power supplies for welding equipment and induction heating systems. Its high voltage and current ratings make it ideal for applications requiring significant power handling capabilities.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the VZ3IM1600M1271 or contact our technical team for cross-reference assistance with compatible TD Series components.
