The Schneider Electric XCC1510PSM03Y is an incremental encoder designed for precise position feedback in industrial automation systems. As part of the XCC series, this encoder features a solid shaft with a 10 mm diameter, suitable for direct mounting in various machinery. It offers a resolution range from 360 to 5760 points per revolution, providing detailed positional data for control applications.

Technical details

• Encoder Type: Incremental Encoder
• Shaft Type: Solid Shaft
• Shaft Diameter: 10 mm
• Resolution: Configurable from 360 to 5760 points per revolution
• Output Signal: Push-Pull (also known as HTL or TTL depending on configuration, buyer should verify datasheet for specific voltage compatibility)
• Series: XCC
• Mounting: Designed for direct shaft mounting
• Power Supply: Requires a specific voltage supply; consult the manufacturer's datasheet for exact requirements.

Applications & compatibility

This encoder is commonly employed in applications requiring accurate rotational measurement and feedback, such as motor control systems, robotics, and automated manufacturing equipment. Its robust design and configurable resolution make it suitable for use in packaging machinery, CNC machines, and material handling systems where precise positioning is critical for operational efficiency.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the XCC1510PSM03Y or contact our technical team for cross-reference assistance with compatible Schneider Electric encoder components.
