The Schneider Electric XCC1510PSM05Y is an incremental encoder designed for precise position feedback in automated machinery. As part of the Schneider Electric encoder family, this unit features a solid shaft and is engineered to provide reliable performance in demanding industrial environments. Its robust construction and specific technical attributes make it suitable for integration into various control systems requiring accurate motion sensing.

Technical details

• Encoder Type: Incremental Encoder
• Shaft Type: Solid Shaft
• Shaft Diameter: 10 mm
• Resolution Options: Configurable from 500 to 8000 points per revolution. Specific resolution for this model is 500 points.
• Output Signal Type: Push-Pull (also known as HTL or TTL depending on configuration, buyer should verify datasheet for specific output voltage compatibility)
• Housing Diameter: 58 mm
• Power Supply: Not specified in provided information; consult manufacturer datasheet for voltage requirements.
• Connection Type: Not specified in provided information; consult manufacturer datasheet for connector type and pinout.

Applications & compatibility

This Schneider Electric incremental encoder is commonly employed in applications demanding accurate rotational feedback, such as motor control systems, robotics, and material handling equipment. It is suitable for integration into CNC machinery, packaging lines, and automated assembly systems where precise positioning is critical for operational efficiency and product quality.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the XCC1510PSM05Y or contact our technical team for cross-reference assistance with compatible Schneider Electric encoder components.
