The Schneider Electric XCC1510PSM11Y is an incremental encoder designed for precise position feedback in industrial automation systems. As part of the XCC series, this encoder features a solid shaft with a 10 mm diameter, suitable for direct mounting in various machine interfaces. It offers a resolution range from 1024 to 16384 points per revolution, providing detailed positional data for control applications.

Technical details

• Series: XCC
• Encoder Type: Incremental
• Shaft Type: Solid Shaft
• Shaft Diameter: 10 mm
• Resolution: Selectable from 1024 to 16384 points per revolution
• Output Type: Push-Pull (also known as HTL or TTL depending on configuration, buyer should verify datasheet for specific output signal compatibility)
• Connection Type: M12 connector (typical for this series, buyer should verify datasheet)
• Operating Temperature Range: Consult manufacturer datasheet for specific environmental ratings.

Applications & compatibility

This encoder is commonly utilized in applications requiring high-resolution position sensing, such as CNC machinery, robotics, automated assembly lines, and material handling equipment. Its robust construction and selectable resolution make it adaptable to a wide range of motion control tasks where accurate feedback is critical for performance and safety.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the Schneider Electric XCC1510PSM11Y or contact our technical team for cross-reference assistance with compatible motion control components.
