The Schneider Electric XCC1514TSM50Y is an incremental encoder designed for precise position feedback in industrial automation systems. As part of the XCC series, this encoder features a through-shaft design, making it suitable for direct mounting on motor shafts or other rotating equipment. Its robust construction and reliable performance are critical for applications requiring accurate motion control and data acquisition.

Technical details

• Encoder Type: Incremental Encoder
• Shaft Type: Through Shaft
• Shaft Diameter: 14 mm
• Resolution: Configurable from 5000 to 80,000 points per revolution (80K points)
• Output Type: Push-Pull (also known as HTL or TTL compatible, depending on configuration)
• Series: XCC
• Housing Diameter: 58 mm
• Power Supply: Verify datasheet for specific voltage requirements (typically 5VDC or 24VDC for push-pull outputs).

Applications & compatibility

This encoder is commonly employed in applications demanding high-resolution position sensing, such as servo motor feedback, robotic arm positioning, and automated assembly machines. Its compatibility extends to various industrial control systems and PLCs that accept incremental encoder inputs via push-pull signals. It is well-suited for use in packaging machinery, CNC equipment, and material handling systems.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the Schneider Electric XCC1514TSM50Y or contact our technical team for cross-reference assistance with compatible XCC series components.
