The Schneider Electric XCCR290RDP12 is a reduction collar specifically designed for use with 90mm encoders. This accessory facilitates the adaptation of encoder shafts, allowing for a transition from a 30mm diameter to a 12mm diameter. It is engineered to ensure secure and precise mounting of the encoder onto machinery with smaller shaft requirements.

Technical details

• Product Type: Reduction Collar
• Manufacturer Series: XCCR (Encoder Accessories)
• Compatible Encoder Diameter: 90 mm
• Shaft Diameter Reduction: From 30 mm to 12 mm
• Material: Typically metal construction for durability in industrial environments (verify with datasheet)
• Mounting Method: Designed for secure attachment to encoder shafts and mating machinery (verify with datasheet)
• Environmental Rating: Suitable for standard industrial operating conditions (verify with datasheet)

Applications & compatibility

This reduction collar is essential for integrating 90mm encoders into machinery where the drive shaft is 12mm in diameter. It is commonly utilized in applications such as motor feedback systems, robotics, automation equipment, and general industrial machinery requiring precise speed or position sensing. Its compatibility ensures proper fitment and reliable operation within various automation setups.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the XCCR290RDP12 or contact our technical team for cross-reference assistance with compatible Schneider Electric encoder accessories.
