The Schneider Electric XCSDMC5902 is a coded magnetic safety switch designed for machine guarding applications. This switch is part of the XCSDMC series, featuring a staggered contact configuration for enhanced safety interlocking. It provides a reliable method for detecting the position of guards and machine doors, ensuring safe operation by preventing machinery startup when guards are open.

Technical details

• Series: XCSDMC
• Contact Configuration: 1 Normally Closed (NC) + 1 Normally Open (NO)
• Actuator Type: Staggered
• Cable Length: 2 meters
• Switching Principle: Coded magnetic
• Safety Function: Guard monitoring and interlocking
• Enclosure Material: Durable plastic
• Ingress Protection Rating: IP67 (refer to manufacturer datasheet for full details)

Applications & compatibility

This safety switch is suitable for use on various industrial machinery and automation systems where reliable guard position detection is critical. Common applications include packaging lines, assembly machines, robotic cells, and CNC equipment. The XCSDMC5902 is designed to integrate with safety relays and controllers to build comprehensive safety circuits.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the XCSDMC5902 or contact our technical team for cross-reference assistance with compatible Schneider Electric safety components.
