The Schneider Electric XPSDM module is a coded magnetic switch designed for safety monitoring applications. This specific unit operates at a 24 V DC supply voltage and is part of the XPSDM series, commonly integrated into machine guarding systems to detect the open or closed state of safety doors and guards. Its coded magnetic switch technology ensures a high level of tamper resistance, crucial for maintaining operational safety standards in industrial environments.

Technical details

• Series: XPSDM
• Product Type: Coded Magnetic Switch Module
• Operating Voltage: 24 V DC
• Switching Technology: Coded Magnetic
• Functionality: Safety monitoring for guard position detection
• Tamper Resistance: High, due to coded magnetic technology
• Compatibility: Designed for integration with compatible Schneider Electric safety relay modules and control systems. For specific compatibility details, please consult the manufacturer's datasheet.

Applications & compatibility

This XPSDM module is essential for safety circuits in automated machinery, including packaging lines, assembly stations, and robotic cells. It is frequently used to monitor the position of safety doors, access panels, and other protective barriers to ensure machinery stops or remains in a safe state when access is attempted. Its robust design makes it suitable for demanding industrial settings.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the XPSDME1132 or contact our technical team for cross-reference assistance with compatible XPSDM components.
