Schneider Electric's XZCC12MDB50R is a shielded M12 connector designed for robust industrial connectivity. This straight, male connector features a 5-pin configuration, commonly employed in sensor and actuator applications within automation systems. Its M12 interface ensures a secure and reliable connection in demanding environments.

Technical details

• Connector Type: M12 Straight Male
• Pin Configuration: 5-Pin
• Shielding: Shielded
• Series: XZCC (Schneider Electric's Sensor and Connector Series)
• Termination Style: Solder or Crimp (verify with datasheet for specific model)
• Housing Material: Typically robust plastic or metal alloy for industrial durability
• Environmental Rating: Designed for industrial environments, often IP67 or IP68 rated (verify with datasheet)
• Electrical Specifications: Voltage and current ratings are dependent on the specific application and wiring configuration; consult the manufacturer's datasheet for precise values.

Applications & compatibility

This XZCC12MDB50R connector is integral to various industrial automation setups, including machine vision systems, proximity sensors, and encoder feedback loops. It is compatible with a wide range of automation controllers and I/O modules that utilize M12 connectivity for signal transmission.

Available from Industrial Automation Co as new, refurbished, or surplus stock, backed by a 2-year warranty with same-day shipping on in-stock items. Request a quote for the XZCC12MDB50R or contact our technical team for cross-reference assistance with compatible Schneider Electric connector components.
